Screw compressor EcoPower 35D 10 bar 35 HP/26 kW 3726 l/min
13.632,04 CHF
Inkl. MwSt.:
13.632,04 CHF
Inkl. MwSt.:
Inkl. MwSt.:
Nicht lieferbar
SKU
36678034-D
- Anfragen? E: info@airpress.de / (+49) 06353 9292924
- Versand nach Österreich? Wechseln Sie zu airpress.at!
Details
| SKU | 36678034-D |
|---|---|
| EAN 13 | 8712418424348 |
| Units per product (pcs.) | 1 |
| Weight (netto) (kg) | 385 kg |
| Length (mm) | 1.200 mm1,2 m |
| Width (mm) | 835 mm8,35 dm |
| Height (mm) | 1.220 mm1,22 m |
| Drive | Gearbox |
| Start | Y-∆ |
| Motor power (hp / kW) | 35.0 HP / 26.0 kW |
| Air-end | C67 |
| Variable speed (IVR) | Nein |
| Control panel | ES 4000 STANDARD |
| Air Receiver | Nein |
| Galvanized tank | Nein |
|---|---|
| Dryer | No |
| Workload (labor/rest %) | 100/0 |
| Maximum pressure (bar) | 10 |
| Free air delivery (l/min) | 3.726 L/m6,21 L/h |
| Free air delivery (m3/h) | 224 m³/h3,733 m³/min |
| Noise level dB (A) (0 m) | 71 |
| Noise level dB(A) (4 m) | 51 |
| Maximum ambient temperature (°C) | 46 |
| Oilfree | Nein |
| Plug type | EU |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| IP classification | IP55 |
